Model: 90D (Plastic 90 Degree Bend)
90 Degree Bend
Colour: White
Max / Min Temp: +60°c to -15°C
Model: FP-CLAMP (Padded Collar/Clamp)

4", 5", 6", 8", 10", 12" Padded Clamps (Collars)

Fast Clamps are perfect for connecting fans, carbon filters, silencer and rigid ducting.

The metal band has a foam lining so reduces fan vibration.

If you need to connect your fan directly to filter for example it's much better to use a padded fast clamp than an connection method such as duct tape.

Heat and humidity in your grow area can often cause duct tape to peel meaning it must be replaced.

Pull out eyelets for easy hanging.

Model: AG METW (Metal Air Valve)

The AG METW is a universally applicable air valve. Because of the materials used, the AG METW is very suitable for use in (very) wet areas like kitchens, bathrooms, etc.



Step less air volume control

Closed adjustment disk

Great air tightness between diffuser body and mounting collar

Suitable for both supply and exhaust air



Model: AG BS (Brushed Steel Air Valve)

The AG is a brushed stainless steel air valve with infinitely adjustable scale, suitable for rooms with high humidity, eg kitchens and bathrooms.



Step less air volume control

High valve body with spring attachment for proper airflow and less noise

Easy to remove for cleaning

Mounting collar included

Suitable for both supply and exhaust air



Model: AG FR (Fire Rated Air Valve)

The Fire Rated Ceiling Valves have been fire tested to BS EN 1365-2:1999 by The Building Test Centre in a full scale horizontal loaded timber joist floor and the ceiling and floor construction with the valves installed, achieved a Fire Rating of over 60 minutes.



The full Test Report BTC 18074F is available to download from our website, together with a Technical Data Sheet and Installation Guide for the Ceiling Valves.



The Fire Rated Ceiling Valves are available in both Supply and Exhaust configurations and incorporate integral intumescent materials. During a fire, the intumescent material expands and closes the aperture of the valve, re-instating the fire resistance of the structure.



Suitable for both supply and exhaust air



Phonetic Ducting Ultra Silent

The NON-WOVEN PMP BLACK consists of a Polypropylene fabric cloth inner duct, thermically and acoustically insulated with a Polypropylene insulation layer and provided with a black polyester outer jacket.  The inner duct is hydrophobic and Anti-Bacterial.

APPLICATION:

Air-conditioning systems

Air supply systems

Preventing condensation in air ventilation systems

Decreasing of machine noises



SPECIFICATIONS  PRESSURE LOSS (STRAIGHT DUCT) Article code: SBIPMPB{Ø}NW

 Temperature range: -30 ⁰C to 140 ⁰C

 Operating pressure: up to +2500 Pa Operating air velocity: max. 25 m/s Min.

 bending radius: 0.54 x Ø + 25mm

Standard diameter range: 102 – 406 mm

Standard length: 3, 6 and 10 mtr



CONSTRUCTION

Inner duct: Non-woven Polypropylene fabric cloth

Insulation blanket PP: 25mm, 16kg/m³

Outer jacket: Poly laminate R-value glass wool: 0.55 m² K/W (ASTM C177-76)

Appearance: Black

The NON-WOVEN PMP BLACK fulfils all the requirements and are classified as specified within EN 13180: Ventilation for buildings – Ductwork - Dimensions and mechanical requirements for flexible ducts.



Model: SW-AD (Door Hatch)
For access to fans, pipes or any items that require to be hidden.
Designed for wall or ceiling mounting.
Open and close by press.
The possibility of universal installation for the left or right-side opening.
Can be used in high-humidity.
Made of high-quality ABS-plastic.

SW-AD1515 - 168 x 168mm (Door Dimensions 146 x 146)
SW-AD2020 - 218 x 218mm (Door Dimensions 196 x 196)
SW-AD3030 - 318 x 318mm (Door Dimensions 296 x 296)
SW-AD3535 - 368 x 368mm (Door Dimensions 346 x 346)

Thickness - 24mm (including flange)

Mounted with glue or cement

Colour: White
