Model: QBF (Quiet Box Fan)
Quiet Box Fan (QBF) fan design allows for supply and extract ventilation for areas/rooms with high requirements to low noise levels and limited mounting space. Units can be installed above ceilings or in loft spaces. Suitable for round ducts. The centrifugal impeller with back-curved blades is powered by means of 2-pole asynchronous motor with external rotor. The motors are equipped with built-in thermal overheating protection with automatic restart.

Sizes/Types

100mm (4") - QBF100
125mm (5") - QBF125
150mm (6") - QBF150
200mm (8") - QBF200
250mm (10") - QBF250
315mm (12") - QBF315
Standard - S
UK Plug - Standard Model Only
Wattage
100mm (4") - 63w
125mm (5") - 63w
150mm (6") - 112w
200mm (8") - 170w
250mm (10") - 173w
315mm (12") - 221w
Air Flow (Free Air)
100mm (4") - 240m3/hr (67l/s)
125mm (5") - 330m3/hr (92l/s)
150mm (6") - 420m3/hr (117l/s)
200mm (8") - 730m3/hr (203l/s)
250mm (10") - 1300m3/hr (362l/s)
315mm (12") - 2150m3/hr (598l/s)
Sound Level dBA
100mm (4") - 33
125mm (5") - 35
150mm (6") - 36
200mm (8") - 38
250mm (10") - 41
315mm (12") - 43
Model: SFP (Plate Fan)
The SFP range is a Commercial Plate Axial Fan perfect for Kitchens, Warehouses, Sports halls, and large areas where high extract rates are needed a low pressure
The SFP Comes in various sizes ranging from 230mm to 480mm

Types/Spigot Size

SFP200 - 230mm
SFP250 - 280mm
SFP300 - 330mm
SFP350 - 380mm
SFP400 - 430mm
SFP450 - 480mm


Pole

SFP200 - 2 Pole

SFP250 - 2 Pole

SFP300 - 2 Pole

SFP350 - 4 Pole

SFP400 - 4 Pole

SFP450 - 4 Pole



Wattage

SFP200 - 55w (0.25 A)
SFP250 - 80w (0.36 A)
SFP300 - 145w (0.66 A)
SFP350 - 135w (0.61 A)
SFP400 - 180w (0.82 A)
SFP450 - 250w (1.14 A)
Air Flow (Free Air)
SFP200 - 890 m3/hr
SFP250 - 1100 m3/hr
SFP300 - 2300 m3/hr
SFP350 - 2600 m3/hr
SFP400 - 3830 m3/hr
SFP450 - 4800 m3/hr
Sound Level dBA (3m)
SFP200 - 50
SFP250 - 60
SFP300 - 61
SFP350 - 62
SFP400 - 63
SFP450 - 64
