Model: CFLO100
Designed to run continuously and provide adequate ventilation for a bathroom, en suite, shower room, wet room. Will provide up to 75% heat recovery

Eliminate mould and control condensation perfect for rented (Buy to let) properties

Condensation Drain fitted to bottom of Unit

Comes pre wired to a trickle and boost switch
Spigots
4" 100mm
UK Plug - UK plug attached

Wattage
Boost - 25w
Trickle – 20w

Air Flow (Free Air)
Boost – 100 m3/hour
Trickle – 30 m3/hour

Sound Level dBA
33dB(A) - High Speed
Designed to run continuously and provide adequate ventilation for a bathroom, en suite, shower room, wet room. Will provide up to 75% heat recovery

Eliminate mould and control condensation perfect for rented (Buy to let) properties

Condensation Drain fitted to bottom of Unit

Comes pre wired to a trickle and boost switch
Spigots
4" 100mm
UK Plug - UK plug attached

Wattage
Boost - 25w
Trickle – 20w

Air Flow (Free Air)
Boost – 100 m3/hour
Trickle – 30 m3/hour

Sound Level dBA
33dB(A) - High Speed
Model: CFLO250
Boost switch comes wired to unit (plug straight in)

W415 x H255 x L450

Designed to run continuously and provide adequate ventilation for a bathroom, en suite, shower room, wet room etc.

Will provide up to 75% heat recovery

Controller is wired to 2 Speeds for trickle and boost

Eliminate mould and control condensation
Trickle/Boost Option included
Loft/void space mounting.

Condensation Drain fitted to bottom of Unit
Spigots
6" 150mm
UK Plug - UK plug attached

Sizes/Types

150mm (6")

Wattage
Speed 1 - 120w
Speed 2 - 106w
Speed 3 - 93w
Speed 4 - 80w
Speed 5 - 65w
Speed 6 - 53w
Speed 7 - 39w

Air Flow (Free Air)
194m3/hr to 550m3/hr

Sound Level dBA
speed 1 : 54dB(A)
speed 2 : 52dB(A)
speed 3 : 47dB(A)
speed 4 : 43dB(A)
speed 5 : 38dB(A)
speed 6 : 34dB(A)
speed 7 : 28dB(A)
Boost switch comes wired to unit (plug straight in)

W415 x H255 x L450

Designed to run continuously and provide adequate ventilation for a bathroom, en suite, shower room, wet room etc.

Will provide up to 75% heat recovery

Controller is wired to 2 Speeds for trickle and boost

Eliminate mould and control condensation
Trickle/Boost Option included
Loft/void space mounting.

Condensation Drain fitted to bottom of Unit
Spigots
6" 150mm
UK Plug - UK plug attached

Sizes/Types

150mm (6")

Wattage
Speed 1 - 120w
Speed 2 - 106w
Speed 3 - 93w
Speed 4 - 80w
Speed 5 - 65w
Speed 6 - 53w
Speed 7 - 39w

Air Flow (Free Air)
194m3/hr to 550m3/hr

Sound Level dBA
speed 1 : 54dB(A)
speed 2 : 52dB(A)
speed 3 : 47dB(A)
speed 4 : 43dB(A)
speed 5 : 38dB(A)
speed 6 : 34dB(A)
speed 7 : 28dB(A)
Model: QBF
Quiet Box Fan (QBF) fan design allows for supply and extract ventilation for areas/rooms with high requirements to low noise levels and limited mounting space. Units can be installed above ceilings or in loft spaces. Suitable for round ducts. The centrifugal impeller with back-curved blades is powered by means of 2-pole asynchronous motor with external rotor. The motors are equipped with built-in thermal overheating protection with automatic restart.

Sizes/Types

100mm (4") - QBF100
125mm (5") - QBF125
150mm (6") - QBF150
200mm (8") - QBF200
250mm (10") - QBF250
315mm (12") - QBF315
Standard - S
UK Plug - Standard Model Only
Wattage
100mm (4") - 63w
125mm (5") - 63w
150mm (6") - 112w
200mm (8") - 170w
250mm (10") - 173w
315mm (12") - 221w
Air Flow (Free Air)
100mm (4") - 240m3/hr (67l/s)
125mm (5") - 330m3/hr (92l/s)
150mm (6") - 420m3/hr (117l/s)
200mm (8") - 730m3/hr (203l/s)
250mm (10") - 1300m3/hr (362l/s)
315mm (12") - 2150m3/hr (598l/s)
Sound Level dBA
100mm (4") - 33
125mm (5") - 35
150mm (6") - 36
200mm (8") - 38
250mm (10") - 41
315mm (12") - 43
Quiet Box Fan (QBF) fan design allows for supply and extract ventilation for areas/rooms with high requirements to low noise levels and limited mounting space. Units can be installed above ceilings or in loft spaces. Suitable for round ducts. The centrifugal impeller with back-curved blades is powered by means of 2-pole asynchronous motor with external rotor. The motors are equipped with built-in thermal overheating protection with automatic restart.

Sizes/Types

100mm (4") - QBF100
125mm (5") - QBF125
150mm (6") - QBF150
200mm (8") - QBF200
250mm (10") - QBF250
315mm (12") - QBF315
Standard - S
UK Plug - Standard Model Only
Wattage
100mm (4") - 63w
125mm (5") - 63w
150mm (6") - 112w
200mm (8") - 170w
250mm (10") - 173w
315mm (12") - 221w
Air Flow (Free Air)
100mm (4") - 240m3/hr (67l/s)
125mm (5") - 330m3/hr (92l/s)
150mm (6") - 420m3/hr (117l/s)
200mm (8") - 730m3/hr (203l/s)
250mm (10") - 1300m3/hr (362l/s)
315mm (12") - 2150m3/hr (598l/s)
Sound Level dBA
100mm (4") - 33
125mm (5") - 35
150mm (6") - 36
200mm (8") - 38
250mm (10") - 41
315mm (12") - 43
Model: SF

The SF range is an inline Axial Fan perfect for small carbon filters or just as a supply/extract fan. This model has a Bracket attached



UK Plug - No



Sizes/Types

100mm (4") - SF100

125mm (5") - SF125

150mm (6") - SF150

Timer - T

Standard - S



Wattage

100mm (4") - 15w

125mm (5") - 20w

150mm (6") - 25w



Air Flow (Free Air)

100mm (4") - 100m3/hr (28l/s)

125mm (5") - 150m3/hr (42l/s)

150mm (6") - 210m3/hr (59l/s)



Sound Level dBA

100mm (4") - 30

125mm (5") - 32

150mm (6") - 35

The SF range is an inline Axial Fan perfect for small carbon filters or just as a supply/extract fan. This model has a Bracket attached



UK Plug - No



Sizes/Types

100mm (4") - SF100

125mm (5") - SF125

150mm (6") - SF150

Timer - T

Standard - S



Wattage

100mm (4") - 15w

125mm (5") - 20w

150mm (6") - 25w



Air Flow (Free Air)

100mm (4") - 100m3/hr (28l/s)

125mm (5") - 150m3/hr (42l/s)

150mm (6") - 210m3/hr (59l/s)



Sound Level dBA

100mm (4") - 30

125mm (5") - 32

150mm (6") - 35

Model: SFP
The SFP range is a Commercial Plate Axial Fan perfect for Kitchens, Warehouses, Sports halls, and large areas where high extract rates are needed a low pressure
The SFP Comes in various sizes ranging from 230mm to 480mm

Types/Spigot Size

SFP200 - 230mm
SFP250 - 280mm
SFP300 - 330mm
SFP350 - 380mm
SFP400 - 430mm
SFP450 - 480mm


Pole

SFP200 - 2 Pole

SFP250 - 2 Pole

SFP300 - 2 Pole

SFP350 - 4 Pole

SFP400 - 4 Pole

SFP450 - 4 Pole



Wattage

SFP200 - 55w (0.25 A)
SFP250 - 80w (0.36 A)
SFP300 - 145w (0.66 A)
SFP350 - 135w (0.61 A)
SFP400 - 180w (0.82 A)
SFP450 - 250w (1.14 A)
Air Flow (Free Air)
SFP200 - 890 m3/hr
SFP250 - 1100 m3/hr
SFP300 - 2300 m3/hr
SFP350 - 2600 m3/hr
SFP400 - 3830 m3/hr
SFP450 - 4800 m3/hr
Sound Level dBA (3m)
SFP200 - 50
SFP250 - 60
SFP300 - 61
SFP350 - 62
SFP400 - 63
SFP450 - 64
The SFP range is a Commercial Plate Axial Fan perfect for Kitchens, Warehouses, Sports halls, and large areas where high extract rates are needed a low pressure
The SFP Comes in various sizes ranging from 230mm to 480mm

Types/Spigot Size

SFP200 - 230mm
SFP250 - 280mm
SFP300 - 330mm
SFP350 - 380mm
SFP400 - 430mm
SFP450 - 480mm


Pole

SFP200 - 2 Pole

SFP250 - 2 Pole

SFP300 - 2 Pole

SFP350 - 4 Pole

SFP400 - 4 Pole

SFP450 - 4 Pole



Wattage

SFP200 - 55w (0.25 A)
SFP250 - 80w (0.36 A)
SFP300 - 145w (0.66 A)
SFP350 - 135w (0.61 A)
SFP400 - 180w (0.82 A)
SFP450 - 250w (1.14 A)
Air Flow (Free Air)
SFP200 - 890 m3/hr
SFP250 - 1100 m3/hr
SFP300 - 2300 m3/hr
SFP350 - 2600 m3/hr
SFP400 - 3830 m3/hr
SFP450 - 4800 m3/hr
Sound Level dBA (3m)
SFP200 - 50
SFP250 - 60
SFP300 - 61
SFP350 - 62
SFP400 - 63
SFP450 - 64
Model: SI
The SI range is a compact inline Axial Fan perfect for small carbon filters or just as a supply/extract fan.
Spigots
The SI Fan has different inlet and outlet spigot diameters to enable attachment to a carbon filter with the outlet side  attaching to your ducting.
UK Plug - EU/UK plug attached
Sound Level dBA
100mm (4") - 35
125mm (5") - 36
150mm (6") - 38

Sizes/Types

100mm (4") - SI100
125mm (5") - SI125
150mm (6") - SI150
Timer - T
Standard - S
Wattage
100mm (4") - 14w
125mm (5") - 18w
150mm (6") - 22w
Air Flow (Free Air)
100mm (4") - 107m3/hr (30l/s)
125mm (5") - 190m3/hr (53l/s)
150mm (6") - 270m3/hr (75l/s)
The SI range is a compact inline Axial Fan perfect for small carbon filters or just as a supply/extract fan.
Spigots
The SI Fan has different inlet and outlet spigot diameters to enable attachment to a carbon filter with the outlet side  attaching to your ducting.
UK Plug - EU/UK plug attached
Sound Level dBA
100mm (4") - 35
125mm (5") - 36
150mm (6") - 38

Sizes/Types

100mm (4") - SI100
125mm (5") - SI125
150mm (6") - SI150
Timer - T
Standard - S
Wattage
100mm (4") - 14w
125mm (5") - 18w
150mm (6") - 22w
Air Flow (Free Air)
100mm (4") - 107m3/hr (30l/s)
125mm (5") - 190m3/hr (53l/s)
150mm (6") - 270m3/hr (75l/s)
Model: SRD
For constant or periodic exhaust ventilation of bathrooms, kitchens and other domestic compartments.

Case and impeller are made from the high-quality ABS-plastic, resistant to ultraviolet.

The motor is equipped with overheating protection.

Fixing to the mounting place is carried out by means of screws.

Types/Spigot Size

SRD100 - 100mm (4")
SRD125 - 125mm (5")
SRD150 - 150mm (6")

Models - Standard (S) & Timer (T)


Wattage
SRD100 - 14w
SRD125 - 18w
SRD150 - 22w
Air Flow (Free Air)
SRD100 - 107 m3/hr
SRD125 - 190 m3/hr
SRD150 - 270 m3/hr
Sound Level dBA (3m)
SRD100 - 35
SRD125 - 36
SRD150 - 38
For constant or periodic exhaust ventilation of bathrooms, kitchens and other domestic compartments.

Case and impeller are made from the high-quality ABS-plastic, resistant to ultraviolet.

The motor is equipped with overheating protection.

Fixing to the mounting place is carried out by means of screws.

Types/Spigot Size

SRD100 - 100mm (4")
SRD125 - 125mm (5")
SRD150 - 150mm (6")

Models - Standard (S) & Timer (T)


Wattage
SRD100 - 14w
SRD125 - 18w
SRD150 - 22w
Air Flow (Free Air)
SRD100 - 107 m3/hr
SRD125 - 190 m3/hr
SRD150 - 270 m3/hr
Sound Level dBA (3m)
SRD100 - 35
SRD125 - 36
SRD150 - 38
Model: ST
The ST range is an inline Centrifugal Fan with attached bracket which can be used for supply or extraction.
This fan is perfect for longer duct runs and carbon filters.
UK Plug - Standard Model Only

Sizes/Types

100mm (4") - ST100
Standard - S
Wattage
100mm (4") - 20w
Air Flow (Free Air)
100mm (4") - 110m3/hr (30l/s)
Sound Level dBA
100mm (4") - 35
The ST range is an inline Centrifugal Fan with attached bracket which can be used for supply or extraction.
This fan is perfect for longer duct runs and carbon filters.
UK Plug - Standard Model Only

Sizes/Types

100mm (4") - ST100
Standard - S
Wattage
100mm (4") - 20w
Air Flow (Free Air)
100mm (4") - 110m3/hr (30l/s)
Sound Level dBA
100mm (4") - 35
Model: STUBE r2
Because of the metal casing there the perfect solution for the installation in exhaust ventilation systems in humid premises such as bathrooms, kitchens etc.

A dynamic balanced impeller with backward curved blades balanced in two planes.
Overheating protection with automatic restart.

Maintenance-free ball-bearings used with motors and designed for at least 40000 hours operation.

Sizes/Types

100mm (4") - STUBE100-R2
125mm (5") - STUBE100-R2
150mm (6") - STUBE100-R2
200mm (8") - STUBE100-R2
250mm (10") - STUBE100-R2
315mm (12") - STUBE100-R2
UK Plug - Yes - with wired Controller
Wattage
100mm (4") - 68w
125mm (5") - 70w
150mm (6") - 125w
200mm (8") - 160w
250mm (10") - 165w
315mm (12") - 165w
Air Flow (Free Air)
STUBE100 - 300 m3/h
STUBE125 - 400 m3/h
STUBE150 - 600 m3/h
STUBE200 - 900 m3/h
STUBE250 - 1000 m3/h
STUBE315 - 1500 m3/hr
Sound Level dBA
100mm (4") - 49
125mm (5") - 49
150mm (6") - 49
200mm (8") - 51
250mm (10") - 52
315mm (12") - 53
Because of the metal casing there the perfect solution for the installation in exhaust ventilation systems in humid premises such as bathrooms, kitchens etc.

A dynamic balanced impeller with backward curved blades balanced in two planes.
Overheating protection with automatic restart.

Maintenance-free ball-bearings used with motors and designed for at least 40000 hours operation.

Sizes/Types

100mm (4") - STUBE100-R2
125mm (5") - STUBE100-R2
150mm (6") - STUBE100-R2
200mm (8") - STUBE100-R2
250mm (10") - STUBE100-R2
315mm (12") - STUBE100-R2
UK Plug - Yes - with wired Controller
Wattage
100mm (4") - 68w
125mm (5") - 70w
150mm (6") - 125w
200mm (8") - 160w
250mm (10") - 165w
315mm (12") - 165w
Air Flow (Free Air)
STUBE100 - 300 m3/h
STUBE125 - 400 m3/h
STUBE150 - 600 m3/h
STUBE200 - 900 m3/h
STUBE250 - 1000 m3/h
STUBE315 - 1500 m3/hr
Sound Level dBA
100mm (4") - 49
125mm (5") - 49
150mm (6") - 49
200mm (8") - 51
250mm (10") - 52
315mm (12") - 53
Model: SW-16/18-CON
16-Way Contactor Double Board & Timer

THIS BOARD MUST BE INSTALLED BY A QUALIFIED ELECTRICIAN

40A Contactor

MDF Board with room in the corners to fix to the wall

Quality 24hr mechanical timer that won’t let you down

16 Timed sockets + 2 Fan Sockets
16-Way Contactor Double Board & Timer

THIS BOARD MUST BE INSTALLED BY A QUALIFIED ELECTRICIAN

40A Contactor

MDF Board with room in the corners to fix to the wall

Quality 24hr mechanical timer that won’t let you down

16 Timed sockets + 2 Fan Sockets
Model: SW-3IN145-COOL
Industrial Cooling Fan

Selectable Speeds - 3
Fan Diameter 45 cm (18")
Wattage - 55w

This cooling fan is the only cooling fan you will ever need. This is due to being designed to be able to be wall mounted, Floor Mounted or as a pedestal fan.

Everything is included in the box to turn this fan in to whichever configuration is required for your room.
Industrial Cooling Fan

Selectable Speeds - 3
Fan Diameter 45 cm (18")
Wattage - 55w

This cooling fan is the only cooling fan you will ever need. This is due to being designed to be able to be wall mounted, Floor Mounted or as a pedestal fan.

Everything is included in the box to turn this fan in to whichever configuration is required for your room.
Model: SW-AD (Door Hatch)
For access to fans, pipes or any items that require to be hidden.
Designed for wall or ceiling mounting.
Open and close by press.
The possibility of universal installation for the left or right-side opening.
Can be used in high-humidity.
Made of high-quality ABS-plastic.

SW-AD1515 - 168 x 168mm (Door Dimensions 146 x 146)
SW-AD2020 - 218 x 218mm (Door Dimensions 196 x 196)
SW-AD3030 - 318 x 318mm (Door Dimensions 296 x 296)
SW-AD3535 - 368 x 368mm (Door Dimensions 346 x 346)

Thickness - 24mm (including flange)

Mounted with glue or cement

Colour: White
For access to fans, pipes or any items that require to be hidden.
Designed for wall or ceiling mounting.
Open and close by press.
The possibility of universal installation for the left or right-side opening.
Can be used in high-humidity.
Made of high-quality ABS-plastic.

SW-AD1515 - 168 x 168mm (Door Dimensions 146 x 146)
SW-AD2020 - 218 x 218mm (Door Dimensions 196 x 196)
SW-AD3030 - 318 x 318mm (Door Dimensions 296 x 296)
SW-AD3535 - 368 x 368mm (Door Dimensions 346 x 346)

Thickness - 24mm (including flange)

Mounted with glue or cement

Colour: White

Login
